Automatic Lamination Machine In Chennai


Specification

Packing details

Model name:SG-3866
Max. lamination width: 380mm
Max. lamination speed: 1-5m/min
Max. lamination temperture: 180C
Max. clearance between top bottom rollers: 6mm
Recommended film: 25-250mic
The maximum diameter of roll film ：200mm Warm up time：about 10 minute
Speed control：manual Auto removing film rewinding
paper：YES Single-sided
laminating function：YES
Double-sided laminating function ：YES
With a perforating blade：YES
Auto paper feeding：YES
Auto slitting paper: Yes
Voltage: 220V/50HZ/1300w
Display: LCD
Heating roller dia: 55
Pull roller dia: 40
Temperature control: IR
Diameter of the core: 1,1.5,3 inch

Package:1pcs/wodden ctn
ctn size: 740*720*580mm G.W:
98kg N.W: 82kg

Model Name: SG-390E
Max. Laminate width: 370mm
Laminate Thickness: 60-800gsm
Max. Laminate speed: 0-10m/min
Heating: By oil
Warming up time: 10min
Max. temperature: 80-125 degree
Operating panel: LCD screen
Feeding paper: Control by rubber roller
Max. thickness of feeding paper: 5cm
Auto paper feeding: YES
Auto cut paper to sheet: YES
Cut film knife: Yes
Perforating knife: Yes
Auto paper feeding: YES
Auto collect paper: YES
Power: 1.6KW


Package:1pcs/Wooden Case
Machine Size: 150*63*120cm
Carton Size: 130*76*110cm
G.W.: 130kgs N.W:110kgs

Model Name: SG-520E
Max. Laminate width: 490mm Laminate Thickness: 60-800gsm Max. Laminate speed: 0-10m/min Warming up time: 10min Heating: By oil
Max. temperature: 80-125 degree Operating panel: LCD screen
Feeding paper: Control by rubber roller
Max. thickness of feeding paper: 5cm Auto paper feeding: YES
Auto cut paper to sheet: YES Cut film knife: Yes Perforating knife: Yes
Auto paper feeding: YES Auto collect paper: YES Power: 1.6KW

Package:1pcs/Wooden Case.
Machine Size: 150*80*120cm
Carton Size: 130*89*111cm
G.W.: 150kgs N.W:130kgs


Model Name: SG-390G
Max. Laminate width: 370mm
Laminate Thickness: 60-800gsm
Max. Laminate speed: 0-10m/min
Warming up time: 10min
Heating: By oil
Max. temperature: 80-125 degree Operating panel: LCD screen Feeding paper: Air suction
Max. thickness of feeding paper: 5cm Auto paper feeding: YES
Auto cut paper to sheet: YES
Cut film knife: Yes
Perforating knife: Yes
Auto paper feeding: YES
Auto collect paper: YES

Package:1pcs/Wooden
Case Machine Size: 188*67*140cm
Carton Size: 134*79*118cm G.W.: 192kgs N.W: 172kgs


Model Name: SG-520G
Max. Laminate width: 490mm
Laminate Thickness: 60-800gsm
Max. Laminate speed: 0-10m/min
Warming up time: 10min
Heating: By oil
Max. temperature: 80-125 degree Operating panel: LCD screen Feeding paper: Air suction
Max. thickness of feeding paper: 5cm Auto paper feeding: YES
Auto cut paper to sheet: YES
Cut film knife: Yes
Perforating knife: Yes
Auto paper feeding: YES
Auto collect paper: YES

Package:1pcs/
Wooden Case Machine Size: 188*80*140cm
Carton Size: 134*92*118cm G.W.: 230kgs N.W:200kgs
